{"product":{"productId":"agid.2820","price":8.28,"name":"Lateral spring plungers, Form A"},"currency":"EUR"}
- Positioning of and holding small parts
- Application sectors: fixture construction, measuring technology
- Steel or hardened stainless steel ball
Description
Material
Body in free-cutting steel.
Ball in stainless steel, hardened.
Spring in stainless steel.
Ball in stainless steel, hardened.
Spring in stainless steel.
Version
Body black oxidised.
Ball bright.
Ball bright.
Note
The lateral spring plunger must be pressed into the hole to at least depth L3. These plungers are for positioning and holding small parts in fixtures. If mechanical machining of the workpiece is to be carried out, other clamps may be necessary. When the fixture is not in use it should be ensured that plastic springs are not under stress.
Spring force refers to a mean value.
Spring force refers to a mean value.
Drawing reference
1) knurl
2) light holding
2) light holding
